Specific torque up to 13 Nmcm3.

Do – Di ratio 1: 55.

The accuracy and stability of high torque twin screw extruder speed control are ensured in terms of the excellent performance of vector-control technique and effective re-developed of its inner functions, through which the whole production system can be more stable, efficient and energy saving.

SCADA (Supervisory Control And Data Acquisition) is a category of software applications for controlling industrial processes, which is the gathering of data in real-time from remote locations to control equipment and conditions.

Segmented screw elements.

Torque limiters protect against damage and downtime caused by machine overloads.

HMI (Human Machine Interface) allows plant operators to view alarms and locate a malfunction in the equipment, allowing them to react more quickly.

Liquid cooling barrel circuit for precise temperature control.

Liquid dosing for TPE compounds.

The shafts are firmly connected to their gearbox by splined shaft couplings.

The barrels are of a modular design and lined with bimetallic liner for versatility and adaptability.

The screws are intermeshed in various shapes, pitches, and metallurgies.

The barrels are equipped with electrical heating shells and liquid cooling systems.

Modification and pelletizing of general-purpose plastics.

Reinforcement and flame radiant of engineering plastic.

Rubber and plastic blending (PS+SBS, PA+EPDM, PP+NBR, EVA+ Silica Rubber).

Alloying plastic (PC+ABS, PA+ABS, CPE+ABS, PP+EPMD, PA+EPMD, PP+SBS).

Grafting and cross-link material (PE crossing-link cable and pipe).

Thermoplastic elastomers (TPE, TPU).

Colouring masterbatches, biodegradable, masterbatch.

Concentrated masterbatch.

Masterbatch special for BOPP.

Ultra-high-molecular-weight polyethylene (UHMWPE) compounds specially for piping.
